SeismAtec 450-A01/A02 - Vexcolt Europe BV
SeismAtec 450-A01/A02
Surface
Smooth transit central pan system
Beweging
Seismic movement capacity
ASTM E-1399
Class I: Thermal
Class II: Wind
Class III: Seismic
Thermal & Wind movement: +/-25.0mm
Traffic Frequency per day
Downloads
Additional information
| Gap width(s) | 50, 75, 100, 150, 200, 250, 300, 400, 500 mm |
|---|---|
| Height(s) | 50, 60 mm |
| Metal type(s) | Aluminium |
| Fire barrier | 120- 240 minutes |
| Waterproofing | Waterproofing membrane |
| Pre-assembly in factory | Contact Atec Profile Systems |
